YSHIELD EMF Shielding Paint PRO54 5 - 1 liter Zoom

EMF Shielding Paint YSHIELD® PRO54 - 1 liter


Out of Stock

£ 47.66

High Frequency and Low Frequency Field Shielding Paint YSHIELD® PRO54 - 1 Liter

Technically our best paint, that is formulated without graphite. One paint for all, if you have high requirements. Based on a high quality pure acrylic binder. Frost resistant: Suitable for shipping during winter time and for sea freights in containers. Breathable, solvent free, low-emission.

This paint is formulated without graphite, which has many advantages:

  • Does not stain off while overpainting with white wall paint.
  • Impacts against the white covering paint don't produce black stripes any more.
  • The surface of the paint film is microporous rough and offers top coatings a catchy underground for excellent adhesion.
  • With 4.8 N/mm² this paint has an extremely high adhesive tensile strength (adhesive power on the underground) for a wall paint, which is 2 times higher than with our graphite paints.
EMF Shielding Graph:
YSHIELD Paint HSF54 EMF Shielding Graph
  • Screening attenuation: One-layer 25 dB (7.5 qm/l) to 30 dB (5 qm/l), two-layer 35 dB (3.75 qm/l) to 40 dB (2.5 qm/l). The shielding attenuation is regularly tested in our own EMC laboratory. We have measurement setups due to the following standards: ASTM D4935-10, IEEE Std 299-2006, IEEEE Std 1128-1998, ASTM A698/A698M-07.
  • Common: Our shielding paints, shielding with carbons have many advantages, see common characteristics.
  • Coverage: One-layer (5 - 7.5 m²/l), two-layer (2.5 - 3.75 m²/l).
  • Underground: Interior and exterior: Excellent adhesion on almost all undergrounds like existing emulsion paints, sheetrock, wallpaper, cement, plaster, masonry, wood, etc.
  • Top coating: Preferably covered with plastic bonded, water-based emulsion paints, dispersion silicate paints, facade paints or silicon resin paints. Not applicable are pure mineral paints (clay, loam, chalk, silicate). Please find appropriate product recommendations in the technical data sheet. Due to the high adhesive tensile strength (to ETAG 004 for EIFS-systems, minimum 0.08 N/mm²), applicable directly under pure organic plaster, no mineral pasters!
  • Grounding: Must be grounded! We recommend interior the grounding strap EB2 plus grounding plate GW (GB) plus GP, exterior the fiber additive AF3 plus the grounding plate GE.
  • Ingredients: Water, pure acrylic dispersion, carbon fibers, carbon black, additives, preservative (MIT, BIT).
  • Technical data: VOC-content: 0.2 g/l (the EU limit value for category A/a is 30 g/l from 2010). Sd-value: 0.1 m. Ph-value: 8. Adhesive tensile strength: 4.8 N/mm². Shelf live: 12 months. Colour: Black. More technical details in our table overview.
  • Fire Safety: Download Fire Safety Report
